599AT EAGLE Tx/Rx 100W

TEN-TEC Model 599AT EAGLE Transceiver, 100 WATTS, IF DSP with Tuner

TEN-TEC Model 599AT EAGLE Transceiver, 100 WATTS, IF-DSP with Tuner

  • TEN-TEC Model 599AT EAGLE Transceiver, 100 WATTS, IF DSP with Tuner

TEN-TEC Model 599AT EAGLE Transceiver, 100 WATTS, IF DSP with Tuner

TEN-TEC has created a 100 watt transceiver combining simplified controls and ease of operation with the excellent performance of a low first IF 160 through 6 meter ham band architecture in a compact, mobile friendly structure. The analog portion of the radio is double conversion with IF frequencies of 9.0015 MHz and 22.5 kHz. A third conversion to zero frequency IF is accomplished in the DSP processor.

The TEN-TEC Model 599 Eagle signifies strength born from DSP technology in HF design. Listening to input from Ham radio operators from around the world led our team of engineers to a remarkable compact yet high performance transceiver that Hams of all ages and skill levels will find a joy to operate.

The large easy to read display can be conveniently configured with your favorite background color and intensity, making your Eagle a pleasure to use as a base, portable, or mobile radio. Flexibility also extends to the Eagle with TEN-TEC’s Sensitune automatic antenna tuner, noise canceling circuitry, and of course TEN-TEC’s famous selective roofing filters.

The TEN-TEC Eagle will truly provide years of outstanding performance unequaled by any other radio in its size or price class. You can be assured the Eagle offers more receiver horsepower with new DSP based architecture, selectable roofing filters, noise reduction, antenna tuner, and of course TEN-TEC’s legendary QSK keying. A tribute to U.S. ingenuity makes the Eagle a radio you can be proud to show your fellow Ham radio operators.

Whether you are a seasoned contester, DX chaser, net operator or a casual operator, the TEN-TEC Eagle has the performance and convenience that will provide years of operating enjoyment!


  • Unlike any other radio in this price class the Eagle offers a combination of DSP and selectable roofing filter options to tailor our listening pleasure. Unlike most transceivers in this price class, TEN-TEC’s unique crystal ladder filters help eliminate undesirable signals from entering the receivers first IF stage making a more enjoyable listening experience even in crowded band conditions.
  • A TEN-TEC first: A user selectable color display which can be tailored to your favorite color and intensity. Different operating environments have varied lighting conditions so why not tailor your radio to meet those needs?  You never have to worry about hearing the weak ones with the fully adjustable DSP noise reduction system used in the Eagle. Eliminating atmospheric band noise is just a push of the button!
  • Tired of noise blankers that seldom work in a mobile environment? TEN-TEC’s unique model 320 optional noise blanker will cancel noise you thought never would be possible.
  • Eagle covers 10 HF amateur bands plus 6 meters along with general coverage receive. Dual VFO’s with SPLIT mode and 100 memories, passband tuning, adjustable AGC, variable CW offset, RIT, built in CTCSS tones for 6 meter FM and TEN-TEC’s legendary silky-smooth QSK for CW and fast switching digital modes. These features add up to one terrific radio!

Included with the 599AT Eagle

  • Factory installed Auto Tuner
  • 320 Noise Blanker
  • SSB and CW Roofing filters in 9 MHz IF and all DSP CW & Sideband filters
  • Owners Manual
  • Model 702 PTT Hand Microphone 8 Pin
  • 1/8” Stereo Plug for key paddles
  • Hex Allen Wrench
  • DC Power Cable
  • Spare 25 Amp Little fuse
  • Warranty Card


599 Programmers Reference Guide v1.001 tt_599_program_ref_v1.001
599 Product Brochure tt_599_product_brochure
599 Modifications for external receiver / SDR panadapter – Rev B tt_599_external_receiver_mod_rev_B
599 User manual v1.009 tt_599_manual_v1.009
599 Block diagram tt_599_block_diagram
599 Schematics tt_599_schematics
599 User input on FLDIGI instructions tt_599_FL_digi_instructions
599 Firmware change log tt_599_change_log
599 Firmware v1.829 tt_599_setup_v1.829.exe
599 Firmware v1.825 tt_599_setup_v1.825.exe
599 Firmware v1.824 tt_599_setup_v1.824.exe
599 Firmware v1.823 tt_599_setup_v1.823.exe
Instructions for disabling software signature enforcement on Windows 8 Disabling_Driver_Signature_Enforcement_on_Windows_8
USB to UART README FIRST tt_599_USB_UART_install_readme
599 USB to UART Installer for 32-bit Windows tt_599_USB32
599 USB to UART Installer for 64-bit Windows tt_599_USB64
USB to UART driver installation instructions v1.XXX tt_599_USB_UART_firmware_install_instructions_v1.x
USB to UART driver installation instructions v2.XXX tt_599_USB_UART_firmware_install_instructions_v2.x
USB to UART drivers for 599 v2.XXX firmware tt_599_USB_UART_driver_v2.x
OmniRig text file for Eagle & Argonaut VI TenTec_Eagle_1
OmniRig .ini file for Eagle & Argonaut VI TenTec_Eagle_1
